Cummins NTA855 Series Engine for Generator Power KTA19-G2

Cummins KTA19-G2 Generator Engine
General Information of Cummins KTA19-G2 Generator Engine
Engine ModelKTA19-G2
Engine Type6 Cylinders, in Line
Displacement18.9 L
Bore*Stroke(mm)159 * 159
CPL Number0520
Net Weight (with flywleel & alternator)1855 KG
Overall Diemension(L*W*H)1324mm*835mm*1183mm


Technical Specification of Cummins KTA19-G2Generator Engine
Fuel SystemPT Pump Direct Injection
AspirationTurbocharged & Intercooled
Governing Rate≤ 5%
Electrical System(Starter Motor/Alternator)12V/24V
Engine Cooling Fluid30L
Engine Oil Volume50 L


Performance Data of Cummins KTA19-G2 Generator Engine
Rated Power/Speed336kW/450HP @ 1500rpm
Standby Power/Speed369kW/495HP @ 1500rpm
Idle Speed At Rated Power575-775r/min
Fuel Consumption @ Continous Power80L/hr
Fuel Consumption @ Rated Power83L/hr
Fuel Consumption @ Standby Power91L/hr
